Cooler Master MasterBox MB311L ARGB Mini Tower Gaming Cabinet
Mini Tower Gaming Cabinet
Dual ARGB Fans
Micro-ATX, Mini-ITX Form Factor
2 x USB 3.2 Gen 1
2x 120mm Pre-installed Fans
Case Size – Mini Tower
Motherboard Support – Micro-ATX, Mini-ITX
Pre-installed Fans – 2x120mm SickleFlow PWM ARGB
PSU Clearance – 140mm
GPU Clearance – 344 mm
OVERVIEW
The Masterbox MB311L ARGB is a Micro-ATX Airflow PC with two ARGB fans pre-installed and built with the latest gaming hardware. The front panel is made entirely of fine mesh, placed between two honeycomb vents on either side to maximize airflow. Since keeping the latest games running smoothly means keeping the latest hardware cool efficiently, top panel ventilation provides the option of adding even more cooling hardware if nothing is mounted, in the form of top panel passive ventilation works.
The internal layout was engineered for high compatibility with the latest gaming hardware, while also accounting for future upgrades. Adhering to the principles of the award-winning MB Series, versatility is combined with a presentation to ensure that any gaming system built inside the Masterbox MB311L ARGB looks as good as it performs.
Large, mesh intakes are spread across each side of the front panel to provide additional airflow to the system. Cooler Master’s fine mesh design on the front panel is proven to provide efficient airflow while filtering out dust.
The drive cage can be moved to the front to accommodate for PSU location, rear to provide additional radiator space, or removed entirely. Hardware, custom-loop cooling, and the builder’s pure pride are shown in a panoramic view through an edge-to-edge tempered glass side panel.
FEATURES:
FINE MESH FRONT PANEL – Cooler Master’s Fine Mesh plan on the front board is demonstrated to give a capable wind current while sifting through the dust.
MESH INTAKES – Huge, network admissions range on each side of the front board to give extra wind stream to the framework.
DUAL ARGB FANS – Two pre-introduced 120mm ARGB fans can be overseen by the motherboard, and associated with the included splitter, to make a far-reaching ARGB lighting framework.
OPTIMIZED AIRFLOW – Wind current is improved by a joint effort between the Fine Mesh front board, extra cross section admissions, top board ventilation, and back exhaust.
TEMPERED GLASS SIDE PANEL – Equipment, custom-circle cooling, and the unadulterated pride of the developer are displayed in an encompassing perspective through an edge-to-edge treated glass sideboard.
ADAPTABLE DRIVE CAGE – The drive confine can move toward the front to oblige for PSU space, in reverse to give extra radiator space, or even totally taken out.
ARGB CONTROLLER – The little ARGB Controller is a small estimated regulator that permits your Addressable RGB, for example, fans and LED strips to be fueled and controlled even in PC frameworks without A-RGB competent motherboard. The regulator accompanies 14 lighting presets to take full advantage of the Addressable LEDs in the framework and permits them to be turned off by lengthy squeezing its button. It is likewise conceivable to connect any outside 2pin button to it to have the option to switch presets without opening the framework. For convenience, Cooler Master permits the RESET button to be alternatively associated with the regulator and utilized as an outside ARGB preset switch button.
TECHNICAL SPECIFICATIONS
SERIES– MasterBox Series
SIZE– Mini Tower
MOTHERBOARD SUPPORT– Micro ATX, Mini ITX
EXPANSION SLOTS– 4
5.25 INCH DRIVE BAYS– N/A
2.5 INCH / 3.5 INCH DRIVE BAYS (COMBO)– 2
2.5 INCH DRIVE BAYS– 2
I/O PANEL– 2x USB 3.2 Gen 1 (formerly USB 3.0), 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack, 1x ARGB 2-to-3 splitter, 1x ARGB Controller (only for the S02 versions)
PRE-INSTALLED FANS FRONT– 2x 120 mm ARGB Fan
FAN SUPPORT TOP– 2x 120/140 mm
FAN SUPPORT FRONT– 3x 120 mm, 2x 140 mm
FAN SUPPORT REAR– 1x 120 mm
RADIATOR SUPPORT TOP– 120 mm, 240 mm
RADIATOR SUPPORT FRONT– 120 mm, 140 mm, 240 mm, 280 mm
RADIATOR SUPPORT REAR– 120 mm
CLEARANCE CPU COOLER– 166 mm/6.54-inch
CLEARANCE PSU– 140 mm (HDD cage in backmost position), 325 mm (w/o front radiator & HDD cage)
CLEARANCE GFX– 344 mm
CABLE ROUTING– 18-22 mm
DUST FILTERS– Top, Front, Bottom
POWER SUPPLY SUPPORT– Bottom mount, ATX
DIMENSIONS (L X W X H)– 435.5 x 217.5 x 410 mm
WEIGHT– 5.47 kg
Specification: Cooler Master MasterBox MB311L ARGB Mini Tower Gaming Cabinet
EAN, GTIN, UPC–
884102069598
Product Type–
PC Cabinets
Brand–
Cooler Master
COLOR–
BLACK
FORM FACTOR–
MINI TOWER
MATERIAL–
MESH, PLASTIC, STEEL, TEMPERED GLASS
SIDE PANEL–
TEMPERED GLASS
MOTHERBOARD COMPATIBILITY–
MICRO-ATX, MINI-ITX
LIGHTING–
ARGB
FANS–
2
RADIATOR COMPATIBILITY–
YES
IDEAL FOR GAMING–
YES
WARRANTY–
2 Years Warranty
