MSI A320M-A Pro Max m-ATX Gaming Motherboard
Supports m-ATX Motherboard Form Factor
Max 64 Gb DDR4 Memory Support
AMD AM4 CPU Socket RYZEN
Supports 1x Realtek 8111H LAN
Dual DIMM Memory Slots
Model – A320M-A PRO MAX
CPU – AMD AM4 Socket
Chipset – AMD A320 Chipset
Max Memory Support – 64 Gb DDR4
Graphics Output Options – HDMI, DVI-D
OVERVIEW
The MSI motherboard has a number of convenient and smart designs, such as a convenient pin-header keep-out zone, friendly SATA and USB location, and more, so that DIY users can choose the gaming rig of their choice. It is essential to cool your PC for reliable performance. The MSI motherboard has an excellent power design with solid and heavy heat sinks. We’ve ensured that you can cool down your system in any way, with full control and adequate fan headings. The MSI motherboard lets you manage speed and temperature for all your system and CPU fans. Total Fan Control lets you test your basic system features in a simplified graphical interface. Integrating MSI DDR4 with Boost technology, we provide maximum compatibility so you can be sure and choose any gaming rig of your choice. The MSI AM4 motherboard fully supports the AMD Ryzen processor.
By integrating MSI Core Boost, you can increase the performance of whatever CPU you use. Power your RYZEN processor with an optimized circuit layout and high-quality power delivery equipment for an incredibly stable operation. Core Boost technology combines MSI’s premium layout and optimized power design to deliver fast and uninterrupted current to the CPU with precision. Not only does it support multi-core CPUs, but it also creates the perfect conditions for your CPU overclocking.
The optimized circuit layout design separates the memory transfer blocks to ensure the stability of the signal, allowing you to enjoy the game with peace of mind. Choose from a preset A-XMP profile in CLICK BIOS 5 and overclock the automatically compatible DDR memory MSI OC Lab has tested and certified these settings for speed and stability. MSI motherboards support all the latest storage standards, allowing users to connect to any ultra-fast storage device. When using Microsoft Windows 10 you will benefit from great compatibility with MSI and a worry-free user experience.
TECHNICAL SPECIFICATIONS
CPU (MAX SUPPORT)_ RYZEN
SOCKET_ AM4
CHIPSET_ AMD A320 Chipset
DDR4 MEMORY_ 1866/ 2133/ 2400/ 2667Mhz (by JEDEC)
2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz (by A-XMP OC MODE)
MEMORY CHANNEL_ Dual
DIMM SLOTS_ 2
MAX MEMORY_ 64 GB
PCI-E X16_ 1
PCI-E X1_ 1
SATAIII_ 4
M.2 SLOT_ 1
RAID_ 0/1/10
LAN_ 1x Realtek 8111H
PCI-E Gen_ Gen3
USB 3.2 PORTS (FRONT)_ 2(Gen1, Type A)
USB 3.2 PORTS (REAR)_ 4(Gen1, Type A)
USB 2.0 PORTS (FRONT)_ 4
USB 2.0 PORTS (REAR)_ 2
REAR AUDIO PORTS_ Realtek ALC892/ALC897 Codec
SERIAL PORTS (FRONT)_ 1
HDMI_ 1
DVI-D_ 1
DIRECTX_ 12
FORM FACTOR_ m-ATX
OPERATING SYSTEM_ Support for Windows 10 64-bit
Support for Windows 7 64-bit
* To support Windows 7 64-bit, you must install an AMD Pinnacle Ridge and Summit Ridge CPU.
Specification: MSI A320M-A Pro Max m-ATX Gaming Motherboard
Product Type_
Motherboards
Brand_
MSI
CPU PLATFORM_
AMD
CPU SOCKET_
AM4
FORM FACTOR_
MICRO-ATX
MEMORY TYPE_
DDR4
CHIPSET_
AMD A320
MAXIMUM MEMORY_
64 GB
WARRANTY_
3 Years Warranty
