Power X PMB-G41 Micro-ATX DDR3 Motherboard
Suitable For Desktop
Intel G41 Chipset
Data Rate DDR3
Maximum RAM Capacity 8 GB
Form Factor Micro-ATX
Form Factor – Micro-ATX
Socket – Supports LGA775 CPU
Chipset – Intel 82G41 + 82801GB
Memory Support – DDR3 up to 8GB
Expansion Slot – 1 x PCI Express x 16 Slot, 1 x PCI Slot
OVERVIEW
The motherboard’s LGA 775 Socket supports Intel CPUs from 1.8 to 3.8 GHz with 533 MHz to 1333 MHz front-side bus frequency. Value for money because the G41 chipset is capable of handling embedded computing applications in need of HD video playback and 3D graphics.
TECHNICAL SPECIFICATIONS
Model_ Power X Motherboard PMB-G41-DDR3
CPU_ Supports LGA775 CPU
Supports FSB 533/800/1066/1333 MHZ CPU
Chipset_ Intel 82G41 + 82801GB
Supports GMAX 4500 Graphics
Memory_ 2 x 240-pin DDR III SDRAM Slots
Memory up to 8GB
Supports dual-channel DDRIII 800MHz/ 1066MHz Memory
BIOS_ AMI BIOS
I/O Interface_ 1 x PS/2 Keyboard Port, 1 x PS/2 Mouse Port, 1 x COM
1 x VGA, 4 x USB 2.0, compatible with USB 1.1
1 x RJ45, 1 x 3 in 1 Audio Port( Line-in, Line out, Mic-in)
Onboard Interface_ 1 x 24-pin ATX Power Connector, 1 x 4-pin ATX 12 V Power Connector
2 x USB Connectors, can support 4 x USB 2.0
1 x F_Audio Connector, 1 x F_Panel Connector, 1 x Speaker Connector
2 x FAN connectors, 4 x Serial ATA connection port, 1 x 40-pin IDE port.
Integrated Sound_ with 6-channel HD Audio codec Onboard
provides front audio interface; provides front stereo mic interface.
Integrated LAN_ with 10/100 Mbps LAN Onboard.
Expansion Slot_ 1 x PCI Express x 16 Slot, 1 x PCI Slot, conformed to PCI v 2.3 specification.
Dimension_ Micro-ATX architecture (172 x 235mm)
Weight_ 660 g (approx)
Specification: Power X PMB-G41 Micro-ATX DDR3 Motherboard
Product Type_
Motherboards
CPU PLATFORM_
INTEL
CPU SOCKET_
LGA775
FORM FACTOR_
MICRO-ATX
Brand_
Power X
CHIPSET_
Intel G41
MAXIMUM MEMORY_
8 GB
IDEAL FOR GAMING_
NO
WARRANTY_
2 Years Warranty
