Intel Core i5-10400F 10th Generation Desktop Processor BX8070110400F – 6 Cores 12 Threads | 4.30 GHz Turbo Frequency | LGA1200 Socket
10th Gen. Intel Core i5-10400F Processor
4.30 GHz Max Turbo Frequency
6 Cores 12 Threads
12 MB Smart Cache
Discrete Graphics Required
Processor Generation – Core i5-10400F 10th Generation
Processor Model Number – Core i5-10400F
Cores & Threads – 6 Cores & 12 Threads
CPU Clock Speed – 2.90 GHz Base & 4.30 GHz Turbo
CPU Socket – LGA1200
Cache Memory – 12 MB Intel Smart Cache
OVERVIEW
This Intel Core i5-10400F 10th Generation Desktop Processor offers great performance and low power usage. The Intel Core i5-10400F 10th Generation Desktop Processor is an excellent choice for high-performance home and office desktops. The Processor comes with a Comet Lake Processor Series and LGA 1200 Socket. Along with that, the Intel Core i5-10400F has 6 cores with 12 threads, a 2.90 GHz base frequency, and a 4.30 GHz maximum turbo frequency. This Intel Core i5-10400F 10th Generation Desktop Processor also has Intel Turbo Boost Technology 2.0 and is built on a 14 nm process. It offers 2 channels of DDR4-2666 memory, up to 128 GB of DDR4 SDRAM, and a TDP of 65 W.
TECHNICAL SPECIFICATIONS
GENERAL_
Product_ 10th Generation Intel Core i5 Processors
Processor Number_ i5-10400F
Vertical Segment_ Desktop
Lithography_ 14 nm
CPU SPECIFICATION_
No. of Cores_ 6
No. of Threads_ 12
Processor Base Frequency_ 2.90 GHz
Max Turbo Frequency_ 4.30 GHz
Cache_ 12 MB Intel Smart Cache
Bus Speed_ 8 GT/s
Intel Turbo Boost Technology 2.0 Frequency_ 4.30 GHz
TDP_ 65 W
MEMORY SPECIFICATION_
Max Memory Size (Dependent On Memory Type)_ 128 GB
Memory Types_ DDR4-2666
Max No. of Memory Channels_ 2
Max Memory Bandwidth_ 41.6 GB/s
SUPPLEMENTAL INFORMATION_
ECC Memory Supported_ No
EXPANSION OPTIONS_
Scalability_ 1S Only
PCI Express Revision_ 3
PCI Express Configurations_ Up to 1×16, 2×8, 1×8+2×4
Max No. of PCI Express Lanes_ 16
PACKAGE SPECIFICATION_
Sockets Supported_ FCLGA1200
Max CPU Configuration_ 1
Thermal Solution Specification_ PCG 2015C
TJunction_ 100°C
ADVANCED TECHNOLOGIES_
Intel Optane Memory Supported_ Yes
Intel Thermal Velocity Boost_ No
Intel Turbo Boost Max Technology 3.0_ No
Intel Turbo Boost Technology_ 2
Intel vPro Platform Eligibility_ No
Intel Hyper-Threading Technology_ Yes
Intel Virtualization Technology (VT-x)_ Yes
Intel Virtualization Technology for Directed I/O (VT-d)_ Yes
Intel VT-x with Extended Page Tables (EPT)_ Yes
Intel Transactional Synchronization Extensions_ No
Intel 64_ Yes
Instruction Set_ 64-bit
Instruction Set Extensions_ Intel SSE4.1, Intel SSE4.2, Intel AVX2
Idle States_ Yes
Enhanced Intel SpeedStep Technology_ Yes
Thermal Monitoring Technologies_ Yes
Intel Identity Protection Technology_ Yes
Intel Stable Image Platform Program (SIPP)_ No
Intel AES New Instructions_ Yes
Secure Key_ Yes
Intel Software Guard Extensions (Intel SGX)_ Yes with Intel ME
Intel OS Guard_ Yes
Intel Trusted Execution Technology_ No
Execute Disable Bit_ Yes
Intel Boot Guard_ Yes
DIMENSION & WEIGHT_
Package Dimension_ 7.1 x 10.6 x 11.9 cm
Item Weight_ 99 gm
Specification: Intel Core i5-10400F 10th Generation Desktop Processor BX8070110400F – 6 Cores 12 Threads | 4.30 GHz Turbo Frequency | LGA1200 Socket
EAN, GTIN, UPC_
0735858445948
CPU PLATFORM_
INTEL
CPU SOCKET_
LGA1200
Product Type_
Processor
Brand_
Intel
PROCESSOR GENERATION_
10TH
PROCESSOR CORES_
6-Core
THREADS_
12
CACHE_
12 MB
INTEGRATED GRAPHICS_
NO
SPEED_
2.9 GHz
TURBO SPEED_
4.3 GHz
PROCESSOR SERIES_
Core i5 (10th Gen)
PERFORMANCE_
GAMING
IDEAL FOR GAMING_
YES
WARRANTY_
3 Years Warranty
