Intel Core i7-12700F 12th Generation Desktop Processor BX8071512700F – 12 Cores, 20 Threads, 4.90 GHz Max Turbo Frequency

Processor Generation – Core i7 12th Generation

Processor Model – i7-12700F

Cores & Threads – 12 Cores & 20 Threads

CPU Clock Speed – 2.10GHz Base & 4.90GHz Turbo

CPU Socket – FCLGA1700

Recommended reading:Intel Core i9-10850K 10th Generation Desktop Processor (Unlocked) – BX8070110850K

Cache Memory – 25 MB Intel Smart Cache

ABOUT Core i7-12700F
Intel Core i7-12700F 12th Generation Desktop Processor Elder Lake desktop processor that comes with 25MB of cache memory. The 12700F has a total of 12 cores (8 performance cores and 4 efficient cores) and 20 threads. This is the best processor CPU ever released by Intel in the i7 range. The processor supports the latest LGA1700 socket and a discrete graphics card is required to receive the display.

In Intel Core i7-12700F 12th Generation Desktop Processor both DDR5 RAM up to 4800 MHz and DDR4 RAM up to 3200 MHz are supported depending on the specific motherboard compatibility. It also supports PCI-E 5.0 if paired with a compatible motherboard. The Intel Core i7-12700F 12th Generation Desktop Processor uses a base power of 65W and maximum power consumption of 180W.

Intel Core i7-12700F 12th Generation Desktop Processor is specially designed for extreme gaming or video editing purposes and comes with a 3-year warranty directly from the Intel brand.

TECHNICAL SPECIFICATIONS

Recommended reading:Intel Core i9-11900K 11th Generation Desktop Processor BX8070811900K – 8 Cores, 16 Threads, 5.30 GHz Max Turbo Frequency

GENERAL_
Product Collection_ 12th Generation Intel Core i7 Processors
Code Name_ Products formerly Alder Lake
Processor Number_ i7-12700F
Lithography_ Intel 7
Vertical Segment_ Desktop
Use Conditions_ PC/Client/Tablet
CPU SPECIFICATION_
Total Cores_ 12
No. of Performance-cores_ 8
No. of Efficient-cores_ 4
Total Threads_ 20
Max Turbo Frequency_ 4.90 GHz
Intel Turbo Boost Max Technology 3.0 Frequency_ 4.90 GHz
Performance-core Max Turbo Frequency_ 4.80 GHz
Efficient-core Max Turbo Frequency_ 3.60 GHz
Performance-core Base Frequency_ 2.10 GHz
Efficient-core Base Frequency_ 1.60 GHz
Cache_ 25 MB Intel Smart Cache
Total L2 Cache_ 12 MB
Processor Base Power_ 65 W
Maximum Turbo Power_ 180 W
SUPPLEMENTAL INFORMATION_
Embedded Options Available_ No
MEMORY SPECIFICATION_
Max Memory Size (dependent on memory type)_ 128 GB
Memory Types_ Up to DDR5 4800 MT/s, Up to DDR4 3200 MT/s
Max no. of Memory Channels_ 2
Max Memory Bandwidth_ 76.8 GB/s
EXPANSION OPTIONS_
Direct Media Interface (DMI) Revision_ 4.0
Max no. of DMI Lanes_ 8
Scalability_ 1S Only
PCI Express Revision_ 5.0 and 4.0
PCI Express Configurations_ Up to 1×16+4, 2×8+4
Max no. of PCI Express Lanes_ 20
PACKAGE SPECIFICATION_
Sockets Supported_ FCLGA1700
Max CPU Configuration_ 1
Thermal Solution Specification_ PCG 2020C
TJUNCTION_ 100°C
ADVANCED TECHNOLOGIES_
Intel Gaussian & Neural Accelerator_ 3.0
Intel Thread Director_ Yes
Intel Deep Learning Boost (Intel DL Boost)_ Yes
Intel Optane Memory Supported_ Yes
Intel SpeedShift Technology_ Yes
Intel Turbo Boost Max Technology 3.0_ Yes
Intel Turbo Boost Technology_ 2
Intel Hyper-Threading Technology_ Yes
Intel 64_ Yes
Instruction Set_ 64-bit
Instruction Set Extensions_ Intel SSE4.1, Intel SSE4.2, Intel AVX2
Idle States_ Yes
Enhanced Intel SpeedStep Technology_ Yes
Thermal Monitoring Technologies_ Yes
Intel Volume Management Device (VMD)_ Yes
SECURITY & RELIABILITY_
Intel Standard Manageability (ISM)_ Yes
Intel AES New Instructions_ Yes
Secure Key_ Yes
Intel OS Guard_ Yes
Execute Disable Bit_ Yes
Intel Boot Guard_ Yes
Mode-based Execute Control (MBEC)_ Yes
Intel Control-Flow Enforcement Technology_ Yes
Intel Virtualization Technology (VT-x)_ Yes
Intel Virtualization Technology for Directed I/O (VT-d)_ Yes
Intel VT-x with Extended Page Tables (EPT)_ Yes
OTHER_
Package Size_ 45.0 mm x 37.5 mm
Specification: Intel Core i7-12700F 12th Generation Desktop Processor BX8071512700F – 12 Cores, 20 Threads, 4.90 GHz Max Turbo Frequency
Brand_
Intel

CPU SOCKET_
LGA1700

CPU PLATFORM_
INTEL

Product Type_
Processor

PROCESSOR SERIES_
Core i7 (12th Gen)

Recommended reading:Intel Core i5-11500 11th Generation Desktop Processor BX8070811500 – 6 Cores, 12 Threads, 4.60 GHz Max Turbo Frequency

PROCESSOR GENERATION_
12TH

PROCESSOR CORES_
12-Core

THREADS_
20

SPEED_
2.10 GHz

TURBO SPEED_
4.9 GHz

Recommended reading:AMD Ryzen 5 3500 3rd Generation Desktop Processor – 6 Core | Up To 4.1GHz

CACHE_
12 MB

INTEGRATED GRAPHICS_
NO

PERFORMANCE_
GAMING

IDEAL FOR GAMING_
YES

WARRANTY_
3 Years Warranty
