MSI MAG Z490 Tomahawk ATX Gaming Motherboard
ATX Form Factor
LGA 1200 CPU Socket
Intel Z490 Chipset
DDR4 Up to 128 Gb Memory
AMD CrossFire Technology
Max CPU Support – i9
Socket – LGA 1200
Form Factor – ATX
DIMM Slots – 4
Operating System – Support for Windows 10 64-bit
TECHNICAL SPECIFICATIONS
CPU_ i9
Socket_ LGA 1200
Processor_ Supports 10th Gen Intel Core 11th Gen Intel Core Pentium Gold and Celeron processors for LGA 1200 socket
Chipset_ Intel Z490 Chipset
Form Factor_ ATX
Memory_ 4 x DDR4 memory slots, support up to 128GB
Supports 1R 2133/2666/2933 MHz
1DPC 1R Max speed up to 5000+ MHz
1DPC 2R Max speed up to 4500+ MHz
2DPC 1R Max speed up to 4400+ MHz
2DPC 2R Max speed up to 4000+ MHz
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel Extreme Memory Profile (XMP)
DIMM Slots_ 4
LAN_ 1x Realtek RTL8125B 2.5G LAN + 1x Intel I219V 1G LAN
Expansion Slots_ 1x PCIe 3.0 x16 slot (from CPU)
Support up to PCIe 4.0 for 11th Gen Intel CPU
Support up to PCIe 3.0 for 10th Gen Intel CPU
1x PCIe 3.0 x16 slot (from chipset, supports x4 mode)
2x PCIe x1 slots (from chipset)
Multi-GPU_ Supports 2-Way AMD CrossFire Technology
Onboard Graphics_ 1x HDMI port supports a maximum resolution of 4096×2160 at 30Hz
1x DisplayPort port supports a maximum resolution of 4096 x 2304 at 60Hz
Storage_ 6x SATA 6Gb/s ports
2x M.2 slots (Key M)
M2_1 slot
CPU support mode (From 11th Gen Intel CPU only)- supports PCIe 4.0 x4/3.0 x4
Chipset support mode-supports PCIe 3.0 x4 and SATA 6Gb/s
Supports 2242/ 2260/ 2280/ 22110 storage devices
M2_2 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280 storage devices 2
Intel Optane Memory Ready 3
Supports Intel Smart Response Technology for Intel Core processors
RAID_ Intel Z490 Chipset
Supports RAID 0, RAID 1, RAID 5, and RAID 10 for SATA storage devices
Supports RAID 0 and RAID 1 for M.2 PCIe storage devices
USB_ Intel Z490 Chipset
1x USB 3.2 Gen 2 10Gbps Type-A port on the back panel
7x USB 3.2 Gen 1 5Gbps (4 Type-A ports on the back panel, 2 ports through the internal USB connector, 1 Type-C internal connector)
2x USB 2.0 ports on the back panel
4x USB 2.0 ports available through the internal USB connectors, hub-GL850G
ASMedia ASM3241
1x USB 3.2 Gen 2×2 20Gbps Type-C port on the back panel
Audio_ Realtek ALC1200-VD1 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
Internal Connectors_ 1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
1x 4-pin ATX 12V power connector
6x SATA 6Gb/s connectors
1x USB 3.2 Gen 1 5Gbps Type-C port
1x USB 3.2 Gen 1 5Gbps connectors (support additional 2 USB 3.2 Gen 1 5Gbps ports)
2x USB 2.0 connectors (support additional 4 USB 2.0 ports)
1x 4-pin CPU fan connector
1x 4-pin water pump connector
6x 4-pin system fan connectors
1x front panel audio connector
2x system panel connectors
1x Chassis Intrusion connector
1x Clear CMOS jumper
2x 4-pin RGB LED connector
2x 3-pin RAINBOW LED connectors
1x serial port connector
1x TPM module connector
1x RTD3 connector
1x TBT connector
Back Panel Ports_ PS/2 Combo Port
DisplayPort
USB 3.2 Gen 2 10Gbps (Type-A)
1G LAN Port
2.5G LAN
HD Audio Connectors
USB 2.0 Ports
HDMI Port
USB 3.2 Gen 2×2 20Gbps (Type-C)
USB 3.2 Gen 1 5Gbps (Type-A)
USB 3.2 Gen 1 5Gbps (Type-A)
Optical S/PDIF OUT
Mounting_ 9 mounting holes
DIRECTX_ 12
Crossfire_ Y
OS_ Support for Windows 10 64-bit
Dimensions_ 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
Specification: MSI MAG Z490 Tomahawk ATX Gaming Motherboard
Brand_
MSI
Product Type_
Motherboards
CPU PLATFORM_
INTEL
CPU SOCKET_
LGA1200
FORM FACTOR_
ATX
MEMORY TYPE_
DDR4
CHIPSET_
Intel Z490
MAXIMUM MEMORY_
128 GB
IDEAL FOR GAMING_
YES
WARRANTY_
3 Years Warranty
